Launch Omnirig and leave it open by not pressing OK. You have to launch VSPE first, before Omnirig. Another version 2.1 with 4 tabs exists and was developed by HB9RYZ. It is recognizable because it has only 2 tabs to control 2 transceivers. Here I recommend the initial version written by VE3NEA because it is easy to add the RemoteSDR.ini file which describes the interface to Remote SDR.
#VSPE 64 BIT LICENSE KEY SOFTWARE#
Omnirig InstallationĪnd you download Omnirig and in the same time the “Client.exe” software which will eventually serve as a test of Omnirig. Be careful to adapt the IP address to your configuration.
#VSPE 64 BIT LICENSE KEY CODE#
You can also take the RemoteSDR.vspe file already available with the Remote SDR source code in the remsdr_Omnirig folder.
#VSPE 64 BIT LICENSE KEY SERIAL#
The system should display 2 green lines “Initialization OK”.Īt this point, everything that arrives at virtual serial port 20, coming from Omnirig, is transmitted to the Remote SDR processor in UDP on port 8008. Launch the assembly emulation with the green arrow. For the port put 8008 in both directions. Put the IP address of the Raspberry Pi or the Orange Pi which processes Remote SDR in reception. You will have to reproduce the same parameters in Omnirig. Choose a speed, the value is of little importance, the flow rate exchanged is low. Then create a device between COM20 and the UDP Manager type LAN network. Take any number, but not in the first digits often occupied by physical USB serial ports of devices connected to the PC. Answer “No”.Ĭlick on the connector with the red star to create a “connector” type virtual serial connector.Ĭhoose a connector number. At each launch, a pop-up asks you for the license. Go to the EterLogic site and download VSPE (usually the 64-bit version). VSPE Installation Virtual Serial Port Emulator And to complicate it a little more, it is above all necessary to launch VSPE first. To manage to make all these little people communicate, the only solution is to go through the processing processor (Raspberry or Orange Pi) of Remote SDR. To adapt to these constraints, we will add the VSPE (Virtual Serial Port Emulator) software to switch from a serial link to the LAN network WSJT-X – Omnirig – VSPE – Remote SDR You have to go through the LAN network with the Http or Websockets protocols. To communicate with the web browser that manages Remote SDR, the possibilities are limited for security reasons. Omnirig makes it possible to link several applications in parallel with all types of transceiver via a serial link.
Many amateur radio applications require communicating with the transceiver using the CAT (Computer Aided Tuning) function. It controls, for example, the transition to transmission or the reception frequency. Omnirig is an interfacing application to control different transceivers by a third party application like (YONIQ-SSTV, WSJT-X…).
